H-Shaped Reclaim System

🔹 H-Shaped Reclaim System – Partial Abrasive Recovery System

We are a leading manufacturer of H-shaped reclaim systems in India, offering advanced partial abrasive recovery systems designed for shot blasting rooms and sand blasting chambers. This system is ideal for medium to high production blasting environments, ensuring efficient abrasive collection, recycling, and cost reduction.

The H-type floor reclaim system is engineered with dual longitudinal screw conveyors positioned along the side walls, allowing heavy workpieces to be placed in the center. This design supports smooth material handling and uninterrupted blasting operations, making it perfect for flow-through blast room setups.

✔ Efficient partial abrasive recovery (60–90%)

✔ Ideal for blast rooms & industrial surface preparation

✔ Supports heavy components & forklift movement

✔ Reduced abrasive wastage & lower operational cost

✔ Optimized for continuous production workflow

🔹 Key Features

Dual side screw conveyor system for effective media collection

H-shaped floor design for easy workpiece positioning

Steel-covered concrete floor for heavy-duty applications

Compatible with forklifts, cranes & material handling systems

Simple design with low maintenance requirements

🔹 Working Principle

During blasting, abrasive media strikes the workpiece and rebounds toward the side walls, where it falls into the longitudinal screw conveyors. These screws automatically transfer the media to the recycling system, achieving up to 90% abrasive recovery. Remaining media is easily pushed into the reclaim system, ensuring efficient reuse and minimal wastage.

🔹 Applications

Shot blasting room systems

Sand blasting chambers

Heavy fabrication & steel industries

Shipyards & structural blasting

Automotive & engineering industries
