U-Shaped Reclaim System

🔹 U-Shaped Reclaim System – Partial Abrasive Recovery System

We are a leading manufacturer of U-shaped reclaim systems in India, delivering advanced abrasive recovery systems for shot blasting rooms and sand blasting chambers. This system is specially designed for medium to high production blasting operations, ensuring efficient abrasive collection, recycling, and reduced material loss.

The U-type floor reclaim system features dual longitudinal screw conveyors along the side walls and a cross screw conveyor at the back wall, forming a U-shaped configuration. This design enables maximum abrasive capture from multiple directions, ensuring 60–90% automatic media recovery during blasting operations.

✔ High efficiency partial abrasive recovery system

✔ Ideal for in-out blast room configurations

✔ Reduced abrasive wastage & cost savings

✔ Suitable for heavy components & industrial use

✔ Designed for continuous production environments

🔹 Key Features

Three-way screw conveyor system (U-shape design)

Efficient abrasive collection from side & back walls

Heavy-duty steel-covered floor for high load capacity

Compatible with forklifts, cranes & handling systems

Low maintenance with high operational reliability

🔹 Working Principle

During blasting, abrasive media rebounds from the workpiece and strikes the side and back walls, where it is collected by the longitudinal and cross screw conveyors. These conveyors transfer the media to the recycling system, achieving up to 90% recovery efficiency. Remaining abrasive is easily directed into the reclaim system, ensuring minimal waste and maximum reuse.

🔹 Applications

Shot blasting room systems

Sand blasting chambers

Heavy fabrication & structural industries

Shipyards & steel processing units

Automotive & engineering sectors
